1328013200 LS Electric

  • 1328013200

Contactors

MC-18a AC120V 50/60Hz 4P (Metasol) EXP (MC18A-40-00-K7-S-E)

LS Electric contactors are electrical devices used to control the switching of electrical circuits, primarily for motors, lighting, heating, and other equipment in industrial and commercial applications. These contactors are critical components in systems that require frequent switching of high-power electrical circuits. LS Electrics contactors are designed for reliable operation, long-lasting performance, and energy efficiency. the 1328013200 or MC18A-40-00-K7-S-E is a 4 NO contactor with screw type terminals and a control voltage of AC120V 50/60Hz frequency. It has 4 poles and an operating voltage up to 690V. It can operate up to 1800 times per hour. It can handle a single phase motor at 1 horse power at 110-220V.

1328013200 Specifications

  • Motor Power: 15hp at 550~600V for 3 phase motors, 10hp at 440~480V for 3 phase motors, 7.5hp at 220~240V for 3 phase motors, 7.5hp at 200~208V for 3 phase motors, 3hp at 220~240V for 1 phase motors, 1HP at 110-220V for 1 Phase Motors
  • UL Standard: UL508
  • Frequency: 50/60Hz
  • Wire Range: #8 to #16
  • Alternate Part Number: MC18A-40-00-K7-S-E
  • Input Voltage: 120V AC
  • Current Rating: 40A
  • Voltage Rating: 690V
  • Number of Poles: 4

1328013200 Technical Resources

In-Stock Qty: 10

45.45
Quantity:
QuantityPrice
1+$45.45
5+$38.54
10+$34.97
30+$31.83
100+$27.88

Call for Availability - 913-362-4248

Call for Availability

913-362-4248
